About This Product
The APD HV_Pro 16S is a high-performance electronic speed controller developed for powerful brushless motor systems. It delivers precise motor control, responsive throttle performance and configurable operating modes for demanding UAV and other electric propulsion applications.
Features
- Supports up to 16S LiPo battery systems.
- High current handling for demanding propulsion applications.
- Smooth motor startup and adjustable throttle response.
- Multiple operating modes, including multirotor and helicopter.
- Automatic motor timing and PWM frequency adjustment.
- Built-in data logging for operating parameters.
- USB-based configuration and firmware updates.
- Integrated protection features for reliable operation.
Technical Specifications
| Specification | Details |
|---|---|
| Model | HV_Pro 16S |
| Brand | APD |
| Product Type | Electronic Speed Controller |
| Maximum Battery Voltage | 68V |
| Maximum Battery Support | 16S LiPo |
| Continuous Current | 400A |
| Burst Current | 600A for up to 5 seconds |
| Peak Power | Up to 30kW |
| Input Signal | PWM |
| Maximum PWM Update Rate | 500Hz |
| Throttle Resolution | 12-bit |
| Maximum Electrical RPM | 1,000,000 eRPM |
| Data Logging | Onboard 16MB flash memory |
| Configuration | USB and APD Configurator |
| Dimensions | 96 × 52 × 26mm |
| Weight | 260g, without cables |
