T-Motor Velox V3120 KV500
T-Motor Velox V3120 KV500 is a powerful cinematic FPV motor designed for 8–11 inch X4/X8 drones, delivering high thrust capability for heavy-payload aerial platforms.
About This Product
The T-Motor Velox V3120 KV500 is a high-power brushless motor developed for cinematic FPV and heavy-lift multirotor platforms. It is designed for 8–11 inch X4/X8 drone configurations and supports a wide 3–12S battery range. The motor incorporates a heat-management design, corrosion-resistant electrophoresis-treated core and high-temperature-resistant components for demanding flight applications.
Features
- 500KV brushless motor
- Designed for cinematic FPV drones
- Suitable for 8–11 inch X4/X8 platforms
- Supports 3–12S LiPo systems
- 12N14P motor configuration
- Proactive heat-dissipation design
- Electrophoresis-treated iron core
- Imported NMB bearings
- High-temperature-resistant windings
- Suitable for heavy-payload applications
- Compatible with selected T-Motor cinematic propulsion systems
Technical Specifications
| Specification | Details |
|---|---|
| Model | V3120 |
| KV Rating | 500KV |
| Motor Type | Brushless DC Motor |
| Configuration | 12N14P |
| Recommended Voltage | 3–12S |
| Motor Dimensions | Ø37.2 × 56.1 mm |
| Shaft Diameter | 5 mm |
| Internal Resistance | 76.35 mΩ |
| Weight incl. Cable | Approx. 146.7 g |
| Lead Wire | 16 AWG |
| Lead Length | 250 mm |
| Idle Current | 0.95 A @ 10V |
| Peak Current | 68.9 A |
| Maximum Power | 3242 W (10 sec.) |
| Recommended Propeller | T-Motor CINE 10.5×5 / compatible 8–11 inch props |
| Recommended Platform | X4 / X8 Cinematic FPV |
| Application | Cinematic FPV / Heavy Lift |
