Designed specifically for multi-rotors, the Navigator Series from Tiger Motors includes some of the best multi-rotor motors available today.
Specifications:
KV…………………………………………………………………………………………………360
Configu ration………………………………………………………………………..12N14P
Stator Diameter………………………………………………………………………..35mm
Stator Length……………………………………………………………………………10mm
Shaft Diameter……………………………………………………………………………4mm
Motor Dimensions(Dia.*Len)…………………………………….Φ41.8×28.5mm
Weight (g)………………………………………………………………………………………97g
ldle current(10)@10v(A)………………………………………………………………..0.4A
No.of Cells(Lipo)………………………………………………………………………….3-6S
Max Continuous current(A)180S……………………………………………………15A
Max Continuous Power(W)180S…………………………………………………330W
Max. efficiency current………………………………………………………..(2-8A)>85%
internal resistance……………………………………………………………………188mΩ
internal resistance……………………………………………………………………188mΩ
