G-HADRON BUNDLE FOR COMPLETE SOLUTION
₹311,700.00
G-Hadron is the ultimate compact and lightweight gimbal, perfectly designed to carry the high-performance dual thermal and visible camera module – Hadron 640R. With its optimized size and weight, G-Hadron ensures a plug-and-play setup for the Hadron 640R.
GENERAL
Built-In Functions
- 1. Operation Modes
- ON/OFF
- Follow mode
- Mapping mode
- 2. New generation IMU Sensor
- 3. Gremsy Specialized Gimbal Drive Motors with Encoders. (Encoder 16 bits)
- 4. USB-C connection.
- 5. Gimbal Mavlink Protocol supported
PLATFORM SUPPORTED
Supported Camera
- Hadron 640R
Supported Drones/Flight Controllers
- Pixhawk/ Cube Pilot / Skynode
MECHANICAL & ELECTRICAL CHARACTERISTICS
Working Current
- Static current: 0.06A
- Dynamic current: 0.1A
- Locked motor current: 2.3A
Operating Temperature
- 14° F ~ 120° F (-10° C ~ 50° C)
Weight
- 164g
Gimbal Dimension (DxWxH)
- 90x63x98 (mm)
PERIPHERAL
Damping Type
- G-Hadron standard damping/ Custom damping
Gimbal Mount
- Bottom
Quick Release
- No
Third Party Control
- Sbus, MAVLink
AUX Signals
- NO
Input power
- 15V-52V
Connections
- USB 2.0, UART, SBus
PC Assistant Software Requirements
- Windows XP or above; Mac OS X 10.9 or above
Mobile Assistant Software Requirements
- iOS 7.1 or above; Android 4.3 or above
WORKING PERFORMANCE
Angular Vibration Range
- ± 0.01°
Maximum Controlled Rotation Speed
- Pan axis: 100°/s
- Tilt axis: 100°/s
- Roll axis: 100°/s
Mechanical Endpoint Range
- Pan axis: ±170°
- Tilt axis: ±170°
- Roll axis: -260° to 80°
Controlled Rotation Range
- Pan axis: ±165°
- Tilt axis: ±120°
- Roll axis: ±40°
